City monitoring | |||||||
Pixel | 200W | focal length | 4. 8-115mm, 23 times optical | Operating temperature | 30℃+65℃ | ||
Video compression | H265/H. 264/MJPEG | power supply | DC12V 18W max | Working humidity | Temperature less than 90% | ||
Resolution and frame rate | Support up to 1920*1080@ 30fps HD picture | Vertical range | -15° ~90° (automatic flip) | Protection level | 1P66: TVS 4000V lightning protection, anti-surge, anti-surge, in line with GB/T17626.54 standard | ||
Minimum illumination | Color 0.005Lux @(F1.6, AGC ON) | Horizontal range | 360° monitoring without dead ends | Local storage | Maximum support 256G | ||
Digital zoom | 16 times | Infrared irradiation distance | 100 metres | ||||
Smart lighting | |||||||
LED type | High power 3535/5050, medium power 3030 | Power factor | >0.9 | Service life | >30000h | ||
Rated power string | 60W-300W | Main light color temperature | 3000~4500 | Working temperature | -20℃~+50℃ | ||
Input voltage | AC220±20% | Color rendering index | ≥Ra70≥ | Working environment humidity | 10%~90% | ||
Frequency Range | 50/60Hz | Main lighting effect (Lm/ | 130 | Protection level | IP65 | ||
Wireless WIFI | |||||||
wireless technology | 802.11N/2T2R 300M MI MO | Operating mode | Gateway mode/AP mode/Universal relay mode | Working environment humidity | 5%~90% | ||
working frequency | 2. 4GHz | Blue radius | 150 meters | Power consumption | 8W | ||
Transmission speed string | 300mbps | Maximum standby | 32 days | power supply | Support 24VPOE power supply | ||
Flash memory | 16M flash memory 128M large memory | Working ring block temperature | -20℃~+50℃ | Features | Wireless connections | ||
Environmental monitoring | |||||||
Meteorological elements | Wind speed. Wind direction, temperature, humidity, pressure PM10, PM2.5 | Operating Voltage | Dc12~30V (Power consumption: 25mA@12V) | Multiple transmission | RS485 | ||
PW2.5 accuracy | ±10‰0-500ug/m | PM10 accuracy | ± 10 ‰ @ 0-1000ug / m 3 | ||||
City radio | |||||||
power | 30W | Noise ratio | ≥70dB | power supply | DC24V | ||
Protocol | ARP, UDP, TcP/iP, IGMP | audio format | WAV (8K.22K). MP3 (32kbps-192kbps) | Operating temperature | -10℃~+70℃ | ||
Audio input sensitivity | 0.775V | Sampling Rate | 8K | Working humidity | 10%~90% | ||
Frequency response | 50Hz-15KHz(±3B) | Harmonic distortion | ≤0.3X | ||||
Information Release | |||||||
Module resolution | P3. 84 | Maximum power | 800W/unit | Protection level | IP65 | ||
Display size | 800mm*1500mm | Average power | 240W/set | Service life | 100000h | ||
Overall size | 900mm*1700mm*90mm | Input power | AC100-240V/50-60Hz | Operating temperature | WC ~ + 5 (TC | ||
brightness | 7000CD/m2 | way to control | 3G.4G/WIFI remote cluster control | Working humidity | 10%~90% | ||
One key alarm | |||||||
Network protocol | TCP/IP UDP. I GMP. RTP | MIC input sensitivity | 10mV | Working humidity | 10%~90% | ||
Audio sampling rate | 16K-48KHZ | Signal to noise ratio | ≥90dB | Working voltage | DC 14V | ||
Broadcast audio format | MP3. WAV | camera | 500W pixels | Power consumption | 6W | ||
Audio mode | 16 stereo CD sound quality | Operating temperature | -20℃+60℃ | ||||
Smart charging pile | |||||||
rated power | 7kw | Start method | Swipe card. AP scan code | Working environment humidity | 10%~90% | ||
charging method | AC single charge | Protection level | ≥IP54 | appropriate types | new energy vehicles | ||
Input voltage | Ac220V±10% | Working environment | -30℃~+50℃ |
Liaoyuan Group is leading LYZ-08 Galvanized Smart Street Light Poles company and LYZ-08 Galvanized Smart Street Light Poles suppliers in China. Liaoyuan has been certificated of ISO9001 QMS, ISO 14001 EMS and OHSMS, and Liaoyuan also passed a series of authoritative certification including GS, CE, ENEC, UL. You can wholesale LYZ-08 Galvanized Smart Street Light Poles easily from us.
